Product Description
CLASSIFICATIONS:
EN ISO 17634-A______EN ISO_17634-B AWS A5.29 AWS A5.29M
T CrMo 2 P M 1 H10 T62T1-1M-2C1M-H10 E91T1-B3M E621T1-B3M
CHARACTERISTICS AND FIELD OF USE:
The welding consumable Union TG CrMo 910R is a low alloyed flux-cored wire with rutile filling, primarily designed for welding of 2.25% Cr and 1% Mo creep-resistant base metals (e.g. 10CrMo9-10), that are used for fabrication of vessels, high-pressure storage tanks and pipe systems. Due to the fast freezing slag system this flux-cored wire provides excellent positional welding characteristics and high travel speeds can be realized. This flux cored wire is designed for welding with normal power sources on DCRP under mixed gas.
BASE MATERIALS:
Creep resistant steels and similar cast steels, quenched and tempered steels up to 980 MPa tensile strength, similar alloyed case-hardened and nitriding steels.
1.7380 – 10CrMo9-10, 1.8075 – 10CrSiMoV7, 1.7379 – G17CrMo9-10 ASTM A335 Gr. P22, A217 Gr. WC9
